Fogatti InstaCool 135 Ⅱ RV Rooftop Air Conditioner | Replaceable Non-Ducted RV AC
As the top 3 brands RV A.C., Fogatti RV A.C. effortlessly fits most market-standard 14'' x 14'' RV openings, seamlessly replacing units from all RV A.C. brands, offering a universal solution with replaceable non-ducted options
- Instant Cool
- Refreshingly Air
- Consistent Comfort
- Gently Audible
- Durable & Reliable Design
- Ultra-low energy consumption
- Extremely effective dehumidification
- Light weight 65.3 lbs
- 13,500 BTU cools, temp range 61-87°F
- 325 CFM airflow for air renewal
- Barely noticeable 62dB noise level
- Remote control with cooling, dehumidifying, blowing, temperature, and speed settings
- Durable shroud to protect from UV light, debris, insects, critters, and weather
- AC 115V/60Hz/1Ph ensures reliable performance
- 13.6A lower amps, recommend 3.5KW generator
- Easy installation with a sleek 14" x 14" design
- Direct replacement for a 14" x 14" fan
1. Coleman：replacement video by Retro Revivals
- The Signature Series
- The Quiet Series
- The PowerSaver Series
- The Roughneck Series
- The Soft Start Series
- The Marine Mach AC
- Specialty Units
2. Dometic：replacement video by shidelrvs
- Penguin II series
- Brisk II series
- Blizzard NXT series
3. Recpro：
- RP-AC3800 Series
- RP-AC3501 Series
- RP-AC2801 Series
- RP-AC3400 Series
- RP-AC48V Series
4. Furrion：
- FACR13HESA-BL-AM
- FACR13HESA-PS-AM
Upon ensuring that the RV's opening dimensions are 14 in x 14 in, a seamless replacement with the Fogatti RV air conditioner is possible without any compromise to the integrity of the vehicle
Free Shipping, 3-5 Days FedEX / UPS Delivery from US Local Warehouse
Columbus Day Deal
Hurry up! Sale will End on
- 30-Day FreeReturn & Replacement
- 30-Day Free Return & Refund
- 24-Month Warranty
Description
FREE Shipping, 3-5 Days FedEX / UPS Delivery
Hear it Straight From Our Pros and Users
Top Rated by Leading RV Retailer & Expert
More and more RV owners and businesses are choosing Fogatti as their preferred A.C. brand. Our high-quality standards in RV cooling, genuinely satisfying after-sales service, and cutting-edge manufacturing technology have earned their trust. Especially with the endorsements from various renowned American RV forums, Fogatti has become a leader in the industry.
Recommended by professional celebrities
shidelrvs
Fogatti makes a tankless water heater that I installed previously, and it works so well. I wanted to try their AC to see how it compared to others. At last, we have a brand new AC installed, and it's blasting cold air. It works great once the installation is finished.
whitehomeonwheels
Who doesn't love a TV lift in a camper? We love ours in our RV, so we knew we had to add one to this camper. We got the TV lift from Amazon and the electric fireplace from @thefogatti. A great way to save on propane in your home on wheels is to add an electric fireplace, and this one heats the space so fast.
with.love.and.dirt
Thanks to the @thefogatti tankless hot waterheater, l have instant and unlimited hotwater. So, bathroom has turned into a spa. lhad no idea how much this hot water heaterwould change my life, but l'm truly happierevery day because of it. Code Ariane10%6 for adiscount using the link in my bio. Enjoy!
not.a.regular.skoolie
This system instantly ensures you have endless hot water in an RV or small cabin. Say goodbye to waiting 10 to 30 minutes for hot water -it's on-demand, guaranteeing you'll have more than enough for showers and daily tasks.
Retro Revivals
Great, it doesn't need much power, so we can use a portable battery power station. Wow, it's cold! The final mode is the dehumidifier indicated by a snowflake and semicircle. This is such a fantastic addition now that professionally installed.
Fogatti dominates the RV AC industry
Fogatti RV Express Cool System
Fogatti RV air conditioner with a powerful air compressor for quick indoor temperature exchange. The large evaporator rapidly expels heat, ensuring a refreshing journey every time!
Air Fast-cooling
Equipped with a high-efficiency condensing compressor motor boasting 1290W power, capable of lowering temperatures to 61°F. Featuring 99.5% pure copper coils for stability and reliability
Powerful Fan
FOGATTI RV AC equipped with a high-speed fan spinning up to 1650 revolutions per minute, this large 8-inch fan is made of PP (Polypropylene), ensuring excellent durability and toughness
Expel Indoor Hot Quickly
The FOGATTI RV AC efficiently expels indoor heat with a 27.6 sq ft evaporator, 342 cooling fins, and 1/4 inch copper tubes, ensuring on-the-go cooling comfort for your journey
Equipped with a high-efficiency condensing compressor motor boasting 1290W power, capable of lowering temperatures to 61°F. Featuring 99.5% pure copper coils for stability and reliability
FOGATTI RV AC equipped with a high-speed fan spinning up to 1650 revolutions per minute, this large 8-inch fan is made of PP (Polypropylene), ensuring excellent durability and toughness
The FOGATTI RV AC efficiently expels indoor heat with a 27.6 sq ft evaporator, 342 cooling fins, and 1/4 inch copper tubes, ensuring on-the-go cooling comfort for your journey
Whisper Breeze Pure Comfort System
Fogatti RV air conditioner – gentle airflow for comfort, low noise for peaceful sleep, and fresh air filtration for a refreshing environment. Elevate your travel comfort with tranquility and innovation.
Soft Air Flow
Optimize the airflow direction through the ADB panel to evenly distribute filtered cold air, preventing discomfort caused by direct airflow to the head
Low Noise Operation
The ultimate solution for enhancing RV journeys and facilitating a peaceful sleep experience, it offers ultra-low operating noise levels, peaking at just 62 decibels
Fresh Air Flow
Equipped with an excellent air filtration system, it effectively filters various harmful particles and irritating gases, ensuring the healthiness of RV travels
Optimize the airflow direction through the ADB panel to evenly distribute filtered cold air, preventing discomfort caused by direct airflow to the head
The ultimate solution for enhancing RV journeys and facilitating a peaceful sleep experience, it offers ultra-low operating noise levels, peaking at just 62 decibels
Equipped with an excellent air filtration system, it effectively filters various harmful particles and irritating gases, ensuring the healthiness of RV travels
Unrivaled RV Climate Mastery
Experience lasting comfort with our rugged RV air conditioner. Durable ABS casing, Antifreezing Mode below 28°F, and enhanced efficiency with solar panels. Elevate your RV experience with innovation!
High-Durability
Crafted from durable ABS material, it features robust resistance to impact, scratches, moisture, and corrosion, guaranteeing exceptional quality and longevity
Antifreezing Mode
The AI-controlled defrost function activates automatically when the temperature dips below 28 degrees Fahrenheit, ensuring the RV air conditioning operates smoothly
Excellent Compatibility
Featuring exceptional energy compatibility, it seamlessly integrates with solar panels, effectively minimizing energy consumption and enhancing sustainability
Crafted from durable ABS material, it features robust resistance to impact, scratches, moisture, and corrosion, guaranteeing exceptional quality and longevity
The AI-controlled defrost function activates automatically when the temperature dips below 28 degrees Fahrenheit, ensuring the RV air conditioning operates smoothly
Featuring exceptional energy compatibility, it seamlessly integrates with solar panels, effectively minimizing energy consumption and enhancing sustainability
RV AC Swift Install Efficiency
Elevate your RV experience with our solar-compatible air conditioner, effortlessly installed for the Mainframe and Distribution Box. Innovation meets sustainability for a journey of unparalleled comfort.
AC Mainframe Installation
Installation Guide for FOGATTI RV Air Conditioner: Detailed instructions and important tips are provided to ensure optimal performance and long-lasting use
ADB Installation
Connect the ceiling assembly or thermostat control wires to the rooftop unit connections. Connect the main power to the rooftop unit according to the manual
Connection Guidelines
Diagram and detailed instructions for connecting the Fogatti RV rooftop air conditioner are provided, ensuring straightforward installation and optimal performance
Installation Guide for FOGATTI RV Air Conditioner: Detailed instructions and important tips are provided to ensure optimal performance and long-lasting use
Connect the ceiling assembly or thermostat control wires to the rooftop unit connections. Connect the main power to the rooftop unit according to the manual
Diagram and detailed instructions for connecting the Fogatti RV rooftop air conditioner are provided, ensuring straightforward installation and optimal performance
Specification
Heat & Cool
Heat & Cool
Cool Only
Powerful cool
Replaceable Non-Ducted RV AC
Replaceable Non-Ducted RV AC
Replaceable Non-Ducted RV AC
Replaceable Non-Ducted RV AC
Polar White
Polar White/Black
Polar White/Black
Polar White
29.5"D x 27.61"W x 14.2"H
29.5"D x 27.61"W x 14.2"H
29.5"D x 27.61"W x 14.2"H
29.5"D x 27.61"W x 14.2"H
11000BTU (With Heat Strip)
15000BTU (With Heat Strip)
13500BTU
15000BTU
Single Zone or Multi-Zone
Single Zone or Multi-Zone
Single Zone or Multi-Zone
Single Zone or Multi-Zone
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
62 dB(A)
62 dB(A)
62 dB(A)
62 dB(A)
115V AC/60 Hz/1 PH
115V AC/60 Hz/1 PH
115V AC/60 Hz/1 PH
115V AC/60 Hz/1 PH
64.4°F～ 86°F（With Heat Strip）
64.4°F～ 86°F (With Heat Strip)
64.4°F～ 86°F
64.4°F～ 86°F
R- 410A
R- 410A
R- 410A
R- 410A
14.25" × 14.25"
14.25" × 14.25"
14.25" × 14.25"
14.25" × 14.25"
ABS Plastic
ABS Plastic
ABS Plastic
ABS Plastic
What's in the Box
FAQ
How many Volts to run this?
It runs on 115 Volts/60HZ, 15.5A.
What is the AC unit size and required hole size?
Main Body Size: 29.5" x 27.6" x 14.2". Standard opening size: 14±1/4" x 14±1/4".
How many amps required to start？
14 amps.
Is there a heater kit for this model ?
Certainly, this device does not have a heating function. However, our other RV air conditioner includes both heating and cooling capabilities.（https://fogattiliving.com/products/15-000-btu-rv-rooftop-air-conditioner-adb-pipe-mounted）
Can I buy a heat kit for this unit ?
There is not a heat kit available, however, we do have a similar unit that already comes with a heating element in it.（https://fogattiliving.com/products/15-000-btu-rv-rooftop-air-conditioner-adb-pipe-mounted）
How to start the cooling mode？
In standby mode, when turning on the machine, it will first start the fan for a self adjustment within 3 minutes, and then start cooling.
When just powered on, press the On-button of the remote controller to cool down.
