Fogatti InstaCool 150 Ⅱ RV Rooftop Air Conditioner | Replaceable Non-Ducted RV AC
As one of the top 3 brands, Fogatti RV A.C. effortlessly fits most market-standard 14'' x 14'' RV openings, seamlessly replacing units from various RV A.C. brands, offering a universal solution with replaceable non-ducted options
- Instant cool
- Toasty warm
- Refreshingly air
- Consistent comfort
- Gently audible
- Durable & reliable design
- Replaceable Non-Ducted RV AC
- Fogatti RV AC weight 65.3 lb
- Ultra-low energy consumption
- Extremely effective dehumidification
- 15,000 BTU cools, temp range 61-87°F
- 325 CFM airflow for air renewal
- Barely noticeable 62dB noise level
- Remote control with cooling, heating, dehumidifying, blowing, temperature, and speed settings
- Durable shroud to protect from UV light, debris, insects, critters, and weather
- AC 115V/60Hz/1Ph ensures reliable performance
- 15.5A lower amps, recommend 3.5KW generator
- Easy installation with a sleek 14" x 14" design
- Direct replacement for a 14" x 14" fan
1. Coleman：replacement video by Retro Revivals
- The Signature Series
- The Quiet Series
- The PowerSaver Series
- The Roughneck Series
- The Soft Start Series
- The Marine Mach AC
- Specialty Units
2. Dometic：replacement video by shidelrvs
- Penguin II series
- Brisk II series
- Blizzard NXT series
3. Recpro：
- RP-AC3800 Series
- RP-AC3501 Series
- RP-AC2801 Series
- RP-AC3400 Series
- RP-AC48V Series
4. Furrion：
- FACR13HESA-BL-AM
- FACR13HESA-PS-AM
Upon ensuring that the RV's opening dimensions are 14 in x 14 in, a seamless replacement with the Fogatti RV air conditioner is possible without any compromise to the integrity of the vehicle
Free Shipping, 3-5 Days FedEX / UPS Delivery from US Local Warehouse
Flash Deal
Hurry up! Deal will End on
- 30-Day Free Return & Replacement
- 30-Day Free Return & Refund
- 24-Month Warranty
Description
Upgrade your RV's air conditioning system with the FOGATTI RV Air Conditioner, designed to provide exceptional cooling performance for a wide range of RV models. With its user-friendly installation process, this package includes an adjustable air distribution box (ADB), a thermostat control kit, and comprehensive instructions for hassle-free setup.
Unmatched Cooling Efficiency: Equipped with a professional-grade LG air compressor, the FOGATTI Van Roof Air Conditioner utilizes advanced technology to deliver cool or warm air to the interior of your RV more efficiently. With R410A refrigerant and a powerful 15,000 BTU dual shaft motor, this unit works harmoniously to cool a 36" trailer in less than 10 minutes, ensuring a comfortable environment even in the harshest conditions.
Built to Last: Constructed with durability in mind, the FOGATTI Camper Top Air Conditioner features a robust ABS shell that maintains its shape and offers excellent resistance to deformation. To combat the effects of prolonged sunlight exposure, the casing is fortified with UV-resistant materials, effectively preventing aging and ensuring long-term performance. The internal air duct is thoughtfully enveloped in EPP foam, providing thermal insulation and safeguarding against external elements such as rain and dust. Enjoy peace of mind knowing that this air conditioning unit is built to handle the demands of RV life.
Superior Air Distribution and Versatility: Experience optimal comfort with the ADB air duct design and adjustable air direction of the FOGATTI Cargo Trauker AC. This innovative system allows you to personalize the air distribution, ensuring that every corner of your RV is cool and comfortable. Whether you're looking for specific cooling zones or uniform air circulation, this unit offers the versatility to meet all your RV air conditioning needs.
Providing Quality Service: With operating requirements of 115V and 15.5A, the FOGATTI RV Rooftop Air Conditioner for Semi Truck is compatible with most RV power supplies, ensuring a smooth installation process. For your peace of mind, we offer an 18-month warranty against any defects in materials or workmanship, demonstrating our commitment to delivering a high-quality product. Additionally, our FOGATTI Fifth Wheel AC Units are designed for easy installation and wiring, saving you valuable time and effort.
Integrated Heating Function: With the built-in 1500W heat strip, the FOGATTI RV Air Conditioner for Travel Trailer goes beyond cooling. This feature effectively removes moisture during damp mornings in the forest and provides ample heating to keep your cabin cozy during early winter trips. When paired with your RV electric fireplace, it creates a truly enjoyable and comfortable winter experience.
Upgrade your RV's cooling capabilities with the FOGATTI RV Air Conditioner, featuring a powerful 15,000 BTU capacity. Designed for easy installation and optimized performance, this quiet AC with heat unit is the ideal solution for any adventure-seeking RV enthusiast.
FREE Shipping, 3-5 Days FedEX / UPS Delivery
Fogatti RV AC Endorsed by Leading RV Forums
More and more RV owners and businesses are choosing Fogatti as their preferred A.C. brand. Our high-quality standards in RV cooling, genuinely satisfying after-sales service, and cutting-edge manufacturing technology have earned their trust. Especially with the endorsements from various renowned American RV forums, Fogatti has become a leader in the industry.
Recommended by professional celebrities
shidelrvs
Fogatti makes a tankless water heater that I installed previously, and it works so well. I wanted to try their AC to see how it compared to others. At last, we have a brand new AC installed, and it's blasting cold air. It works great once the installation is finished.
whitehomeonwheels
Who doesn't love a TV lift in a camper? We love ours in our RV, so we knew we had to add one to this camper. We got the TV lift from Amazon and the electric fireplace from @thefogatti. A great way to save on propane in your home on wheels is to add an electric fireplace, and this one heats the space so fast.
with.love.and.dirt
Thanks to the @thefogatti tankless water heater, l have instant and unlimited hot water. So, the bathroom has turned into a spa. I had no idea how much this water heater would change my life, but I'm truly happier every day because of it. Code Ariane10%6 for a discount using the link in my bio. Enjoy!
not.a.regular.skoolie
This system instantly ensures you have endless hot water in an RV or small cabin. Say goodbye to waiting 10 to 30 minutes for hot water -it's on-demand, guaranteeing you'll have more than enough for showers and daily tasks.
Retro Revivals
Great, it doesn't need much power, so we can use a portable battery power station. Wow, it's cold! The final mode is the dehumidifier indicated by a snowflake and semicircle. This is such a fantastic addition now that professionally installed.
Fogatti dominates the RV AC industry
Intense Warmth, Swift Cooling RV Marvel
Fast Cooling, Powerful Fan – Banish indoor heat instantly. Master RV climate, efficiency, and comfort – all in reach!
Air Fast-cooling
Equipped with a high-efficiency condensing compressor motor boasting 1290W power, capable of lowering temperatures to 61°F. Featuring 99.5% pure copper coils for stability and reliability
Powerful Fan
FOGATTI RV AC equipped with a high-speed fan spinning up to 1650 revolutions per minute, this large 8-inch fan is made of PP (Polypropylene), ensuring excellent durability and toughness
Expel Indoor Hot Quickly
The FOGATTI RV AC efficiently expels indoor heat with a 27.6 sq ft evaporator, 342 cooling fins, and 1/4 inch copper tubes, ensuring on-the-go cooling comfort for your journey
Equipped with a high-efficiency condensing compressor motor boasting 1290W power, capable of lowering temperatures to 61°F. Featuring 99.5% pure copper coils for stability and reliability
FOGATTI RV AC equipped with a high-speed fan spinning up to 1650 revolutions per minute, this large 8-inch fan is made of PP (Polypropylene), ensuring excellent durability and toughness
The FOGATTI RV AC efficiently expels indoor heat with a 27.6 sq ft evaporator, 342 cooling fins, and 1/4 inch copper tubes, ensuring on-the-go cooling comfort for your journey
Whisper Breeze Pure Comfort System
Enhance on-the-go comfort: Dry Air, Soft Flow, Low Noise, Fresh Breeze. Elevate travel where tranquility meets efficiency!
Comfortable Dry Air
Ensuring optimal temperature levels in comfortable humidity conditions, it boasts effective space control capabilities to enhance comfort, providing a pleasant environment
Soft Air Flow
Optimize the airflow direction through the ADB panel to evenly distribute filtered cold air, preventing discomfort caused by direct airflow to the head
Low Noise Operation
The ultimate solution for enhancing RV journeys and facilitating a peaceful sleep experience, it offers ultra-low operating noise levels, peaking at just 62 decibels
Fresh Air Flow
Equipped with an excellent air filtration system, it effectively filters various harmful particles and irritating gases, ensuring the healthiness of RV travels
Ensuring optimal temperature levels in comfortable humidity conditions, it boasts effective space control capabilities to enhance comfort, providing a pleasant environment
Optimize the airflow direction through the ADB panel to evenly distribute filtered cold air, preventing discomfort caused by direct airflow to the head
The ultimate solution for enhancing RV journeys and facilitating a peaceful sleep experience, it offers ultra-low operating noise levels, peaking at just 62 decibels
Equipped with an excellent air filtration system, it effectively filters various harmful particles and irritating gases, ensuring the healthiness of RV travels
Unrivaled RV Climate Mastery
Optimized RV Climate: Antifreeze Mode, Perfect Compatibility. Elevate your journey where tech meets performance！
High-Durability
Crafted from durable ABS material, it features robust resistance to impact, scratches, moisture, and corrosion, guaranteeing exceptional quality and longevity
Antifreezing Mode
The AI-controlled defrost function activates automatically when the temperature dips below 28 degrees Fahrenheit, ensuring the RV air conditioning operates smoothly
Excellent Compatibility
Featuring exceptional energy compatibility, it seamlessly integrates with solar panels, effectively minimizing energy consumption and enhancing sustainability
Crafted from durable ABS material, it features robust resistance to impact, scratches, moisture, and corrosion, guaranteeing exceptional quality and longevity
The AI-controlled defrost function activates automatically when the temperature dips below 28 degrees Fahrenheit, ensuring the RV air conditioning operates smoothly
Featuring exceptional energy compatibility, it seamlessly integrates with solar panels, effectively minimizing energy consumption and enhancing sustainability
RV AC Swift Install Efficiency
Effortless RV climate control: AC Mainframe, ADB Installation, Connection Guidelines. Upgrade your journey, all in your hands!
AC Mainframe Installation
Installation Guide for FOGATTI RV Air Conditioner: Detailed instructions and important tips are provided to ensure optimal performance and long-lasting use
ADB Installation
Connect the ceiling assembly or thermostat control wires to the rooftop unit connections. Connect the main power to the rooftop unit according to the manual
Connection Guidelines
Diagram and detailed instructions for connecting the Fogatti RV rooftop air conditioner are provided, ensuring straightforward installation and optimal performance
Installation Guide for FOGATTI RV Air Conditioner: Detailed instructions and important tips are provided to ensure optimal performance and long-lasting use
Connect the ceiling assembly or thermostat control wires to the rooftop unit connections. Connect the main power to the rooftop unit according to the manual
Diagram and detailed instructions for connecting the Fogatti RV rooftop air conditioner are provided, ensuring straightforward installation and optimal performance
Specification
Cool Only
Cool & Heat Pump
Powerful cool
Replaceable Non-Ducted RV AC
Replaceable Non-Ducted RV AC
Replaceable Non-Ducted RV AC
Polar White/Black
Polar White/Black
Polar White
29.5"D x 27.61"W x 14.2"H
29.5"D x 27.61"W x 14.2"H
29.5"D x 27.61"W x 14.2"H
13500BTU
15000BTU（With heat pump）
15000BTU
Single Zone or Multi-Zone
Single Zone or Multi-Zone
Single Zone or Multi-Zone
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
Mechanical Air Distribution Box or Return Air Grille w/ wall thermostat control kit or air distribution box w/ thermostat control kit
62 dB(A)
62 dB(A)
62 dB(A)
115V AC/60 Hz/1 PH
115V AC/60 Hz/1 PH
115V AC/60 Hz/1 PH
64.4°F～ 86°F
64.4°F～ 86°F（With heat pump）
64.4°F～ 86°F
R- 410A
R- 410A
R- 410A
14.25" × 14.25"
14.25" × 14.25"
14.25" × 14.25"
ABS Plastic
ABS Plastic
ABS Plastic
What's in the Box
FAQ
How many Volts to run this?
It runs on 115 Volts/60HZ, 15.5A.
What is the AC unit size and required hole size?
Main Body Size: 29.5" x 27.6" x 14.2". Standard opening size: 14±1/4" x 14±1/4".
How to start the cooling mode？
In standby mode, when turning on the machine, it will first start the fan for a self adjustment within 3 minutes, and then start cooling.
When just powered on, press the On-button of the remote controller to cool down.
What size hole is needed in the RV roof for installing this air conditioning unit?
Optimized: A 14-inch by 14-inch opening is required.
Is it possible to install this RV AC on a curved roof RV?
Optimized: Ideally installed on a flat roof with an inclination of less than 5 degrees.
